Live from Wembley: First-ever live broadcast to mobile with HD HDR

For the Spurs v Juventus UEFA Champions League clash on Wednesday 7 March at Wembley Stadium, BT Sport and UK mobile network operator EE carried out the first-ever test of HD HDR live broadcast to mobile devices.

Spurs vs Juventus in the Champions League, broadcast in HD HDR to a mobile device

The match, which was won 2-1 by the Italian team, was broadcast successfully to a beta version of the BT Sport App and the picture quality, in comparison to standard HD, was significantly better and equivalent to a 4K experience, according to the operator. EE stated that the test showed that 4K was not needed for mobile device broadcasts.

As to why the broadcast was carried out, Matt Stagg, Head of Media and Entertainment at EE, told SVG Europe that it was about helping bring a true live broadcast experience to fans without using up their data allowance. “This is the first time an HD HDR live broadcast has been done to mobile. A lot of people think that 4K is the ultimate experience, however, on mobile your eyes can barely tell the difference between HD HDR and 4K due to the screen size and the distance of the screen to your face.

“We think that the ultimate experience on mobile is HD HDR; the enhanced colour spectrum that HDR gives really helps to immerse the fan in the experience, in fact, it isn’t possible to see the colours that HD HDR provides on a mobile device unless you are seeing it with your own eyes, live in the stadium,” Stagg added.

He continued: “Also, 4K takes up a huge amount of bandwidth and data in consumers’ packages, so effectively they would use up to two and a half times more mobile data for a 4K experience that their eyes can’t differentiate from HD HDR.”

Paolo Pescatore, VP multiplay and media, CCS Insight, was present at the match and commented on the trial: “For me, this proof of concept was a success. Being the 4K junkie that I am, I was sceptical. It worked very well in a congested environment and the picture quality was superb.”

Pescatore added: “After last night, I would say a combination of HD and HDR is probably better suited for smaller screens. Not only does it provide an amazing picture quality, it provides other plentiful benefits. In particular, the bandwidth requirements of delivering a live HD and HDR stream are far less than 4K; around 7MBps rather than around 16-20MBps for 4K. For consumers, there will be an added benefit of less data usage as well as much higher eligibility whilst mobile. Also, for mobile network operators, it would seem that the economics of delivering live video in these formats makes more sense than delivering in 4K.”

BT-owned EE chose to run the trial at the Spurs v Juventus match as it brought together the strength of the team, with BT Sport owning the rights to the match and delivering the production side, and EE providing the mobile network and top end devices.

BT Sport’s production of the match used its standard Champions League set up of 24 Sony HDC-4300 cameras around the stadium. Andy Beale, chief engineer at BT Sport, explained: “The nice feature about the Sony 4300’s is they have two outputs; one does normal 4K SDR and the other does 4K HDR. The only thing different in the set up for this broadcast is a second slave SAM Kahuna vision mixer that follows what the primary mixer does, so you have two completely different signals that mirror each other. The second HDR vision mixer also up-maps the few non-SDR sources such as RF cameras to HDR.

“We create a 4K HDR Master and convert that to HD 1080p 50 and send it from here in the stadium to the BT Tower over a standard BT link, and the BT Tower splits it and sends it to our lab in Ipswich,” noted Beale. “We have one Elemental encoder at the BT Tower and one at Ipswich which takes the full HD video and adapt the bit rate for a number of different profiles for mobile devices. Those are packaged and sent out into the cloud.”

EE and BT Sport tested two cloud providers on the night of the live broadcast; AWS Elemental Cloud (BT Sport’s usual provider) for one feed, and Harmonic’s VOS cloud for the other. Akamai, which provides BT Sport’s CDN service, was also used.

Stagg concluded: “After a lot of trials and consumer groups, we had confirmed what we thought was right; that HD with HDR is far superior to 4K on a mobile device.”
