Blackmagic Design live production infrastructure specified for America’s Cup World Series event

Image credit: America’s Cup World Series.

Image credit: America’s Cup World Series.

Hosting a major four-day live production, spanning more than a square kilometer of land and sea, is no easy feat. Not only does it take precision planning and a crack team of experienced professionals, but it also requires a robust and reliable audio visual workflow, capable of flawless performance.

Fonix LED Ltd was drafted in by organisers of the America’s Cup World Series to support the opening regatta of the 2017 cycle, taking place for the first time in its history on the Solent hub of Portsmouth, England, in late July. Fonix brought to bear all of its knowledge and technical expertise on this project – including dealing with wind speeds that topped 30 knots, forcing organisers to abandon racing on the final day.

“The brief was vast,” says live camera director Colin Parnell. “Multiple feeds, multiple locations, full camera coverage of the event, at sea and on the festival site, password-protected live streaming and screens positioned around Portsmouth as well as in the fan zone, waterfront arena and VIP areas. We were also required to support the broadcasters and take live feeds from them.”

Public areas

Image credit: America’s Cup World Series.

Image credit: America’s Cup World Series.

The fan zone was a dedicated space for paying spectators whilst the waterfront arena was a full sized festival stage, open to the general public. Spectators in the fan zone were given an excellent view of the water, plus a giant LED screen and local stage with exclusive content. Fonix’s local production team covered the zone using several long lens positions, and a further two microwave linked roving cameras. For the wider public, organisers also hosted a waterfront arena with a festival stage, flanked on either side by two big LED screens and hosting performances by McBusted, Wet Wet Wet and Spandau Ballet, all of which were covered by Fonix’s production crews.

It proved to be a very complex setup, particularly in regards to audio, with challenges in embedding and de-embedding audio, as Fonix had to feed a large number of analogue systems throughout the four day regatta. Due to the terrain, the workflow was based on a mix of optical fiber, for distances from 70m up to 600m, and SDI, as well as microwave radio links, all of which were patched to a Smart Videohub 20 x 20 router from Blackmagic.

“We were taking auxiliary feeds from a pair of ATEM 2 M/E Production Studio 4K’s, in use at each of our two local production hubs, the waterfront arena and fan zone, as well as an ATEM Television Studio to give us additional HDMI inputs,” says Parnell. “We relied on a whole series of Blackmagic’s Mini Converters to embed and de-embed audio. The ATEMs audio capabilities were also pushed to the limits with every input including embedded audio, and the ATEM 2 main audio outputs being fed to a separate desk, the audio monitor output to another one. It meant the ATEM was effectively de-embedding more than 12 channels of audio. “

For graphics, Fonix opted for Livestream Studio software running on a PC equipped with a DeckLink I/O capture board, giving the production team an SDI feed for the vision mixer.

“This was extremely effective and gave us animated backdrops, which we played from ATEM’s internal media player. The ability to play VTs behind graphics affords tremendous flexibility, and the spreadsheet style implementation is quick and easy, particularly when updating lower thirds and captions. Blackmagic’s DeckLink board provides a perfect signal for keying too.”

Extensive coverage

During the four days, event television played a big part. America’s Cup TV (ACTV) was live on air to spectators from 10am Thursday morning, and then each day until 7pm, uninterrupted. Race feeds were only available for several hours each day, across the Saturday and Sunday.

Of the extensive coverage requirements, Parnell notes: “Our XJ95 and HJ40 long lenses allowed us to acquire excellent shots of all the craft on the water, and provided great close-ups of the America’s Cup contenders when they came out for practice. We used a wireless tally system, which we connected to Blackmagic’s vision mixers using their GPI and Tally Interface. This set-up gave our camera operators wireless tally, including preview and TX.

“The fan zone and waterfront stage each had its own production team responsible for producing local content, all of whom worked tirelessly throughout that period to keep it entertaining and factual, whilst also providing up-to-the-minute information to spectators and fans.”

Fonix also supplied those feeds to Southsea Castle, the VIP areas, a number of the competing teams’ own exclusive areas and a very busy media centre – where Fonix had fitted a 3mm high resolution indoor screen.

Blackmagic Design’s live production hardware was involved in every aspect of Fonix’s workflow at the regatta, reveals Parnell: “Every video signal was patched through an ATEM vision mixer, Smart Videohub, mini converter or DeckLink I/O cards. Blackmagic’s hardware touched every single video signal.

“For me, the true extent of the ATEM’s power and capabilities was realised on this event, with every single auxiliary in use, every input populated. We had so many different demands placed on us for feeds that the ATEM almost doubled-up as a matrix. We also used the wonderful Supersource, both DSKs for logos and the MEs for lower thirds, and the flexibility of the MEs to give us multiple mixes. We used the ATEM Broadcast Panels and ATEM Software Control extensively.

“We had five separate laptops set up at each of the two local production hubs, providing us with feeds for VT playback, including feature videos, ad rolls, and animated graphics. We used two HyperDeck Studio Pro broadcast decks to record the program output, both the primary and backup. We also had a HyperDeck Shuttle connected to a roving camera to gain “as live” content, which we then played back from a third Blackmagic broadcast deck as a source player.”
